Biesse ROVER PLAST A FT 1224 machining centre
Kaiserslautern
If you decide to buy equipment at a low price, make sure that you communicate with the real seller. Find out as much information about the owner of the equipment as possible. One way of cheating is to represent yourself as a real company. In case of suspicion, inform us about this for additional control, through the feedback form.
Before you decide to make a purchase, carefully review several sales offers to understand the average cost of your chosen equipment. If the price of the offer you like is much lower than similar offers, think about it. A significant price difference may indicate hidden defects or an attempt by the seller to commit fraudulent acts.
Do not buy products which price is too different from the average price for similar equipment.
Do not give consent to dubious pledges and prepaid goods. In case of doubt, do not be afraid to clarify details, ask for additional photographs and documents for equipment, check the authenticity of documents, ask questions.
The most common type of fraud. Unfair sellers may request a certain amount of advance payment to “book” your right to purchase equipment. Thus, fraudsters can collect a large amount and disappear, no longer get in touch.
- Transfer of prepayment to the card
- Do not make an advance payment without paperwork confirming the process of transferring money, if during the communication the seller is in doubt.
- Transfer to the “Trustee” account
- Such a request should be alarming, most likely you are communicating with a fraudster.
- Transfer to a company account with a similar name
- Be careful, fraudsters may disguise themselves as well-known companies, making minor changes to the name. Do not transfer funds if the company name is in doubt.
- Substitution of own details in the invoice of a real company
- Before making a transfer, make sure that the specified details are correct, and whether they relate to the specified company.
Seller's contacts
+49 162 58...
+49 162 5858448
Germany, Kaiserslautern
Germany, Kaiserslautern
Germany, Kaiserslautern
Germany, Kaiserslautern
Germany, Location:munich
Germany, Kaiserslautern
Germany, Kaiserslautern
Germany, Kaiserslautern
Germany, Kaiserslautern
Germany, Kaiserslautern
Germany, Kaiserslautern
50 Hz
Germany, Kaiserslautern
Germany, Kaiserslautern
Location: DE
Working Area / Table Dimensions: X = 2465 mm, Y = 1260 mm
Z-Axis Stroke: 378 mm
Maximum Axis Speed: X = 85 m/min, Y = 60 m/min, Z = 20 m/min
Maximum Piece Passage in Z: 200 mm (170 mm with Sweeper Arm)
Worktable Type: FT PLUS phenolic layer table with 30 mm grid layout, 12 mm MDF matrix plate
Vacuum System: Multi-zone vacuum system (4 independent zones)
Vacuum Pump: 1x 250 m³/h cam vacuum pump (dry running, maintenance free)
Machining Unit: 5-interpolating axes machining unit, 13 kW (17.4 HP) S6 / 11 kW S1, HSK F63 adapter, liquid-cooled, up to 20,000 RPM
Axis Angles: C-axis 360° continuous rotation, B-axis +/- 150°
Coolant Unit: Liquid cooling system (absorbs 1600 W) for electrospindle
Measuring Systems: Digital tool length presetter (for diameters up to 130 mm)
Software: BH660 PC-based control with WRT (Windows Real Time), bSolid (3D CAD/CAM), bSolid 3-Axis & 5-Axis machining modules, bNest (Nesting module), bSolid File Import Module
Vacuum modules: 6x (132x146 H74mm), 4x (132x75 H74mm), 4x (132x54 H74mm)
Power Supply: 400 V / 50 Hz, 3-phase (without neutral conductor), voltage tolerance +/-10%
Safety Standard: CE / UKCA with Full Bumper safety system and protective enclosure
Tool Tool Changer / Magazines
13/16-position linear side tool changer mounted on machine bed
8-position revolving tool changer mounted on X-carriage
Additional Features
LED light strip for work area illumination & L-shaped LED projector for vacuum pod positioning
Ionizer for static charge reduction on plastics
Tool lubrication system (air-oil mist) for non-ferrous material processing
Wired remote control pad
Uniclamp adapters (4x) and Uniclamp clamping devices (4x
H=74mm)
Air cushion blower for easy loading/unloading
Barcode scanner (1D wireless)
UPS backup for machine PC (7-10 min power backup)
